Fox 2021-2026 Ford Bronco 2.5 IFP Rear Coilover 0-3 Inch Lift Performance Series HTO FOX98762001

Features:

• 2.5” Impact extruded 6061-T6 aluminum shock body
• Type II clear-anodized body plating
• High-flow velocity-sensitive damping 5/8” hard chrome shaft Internal floating piston (IFP)
• Hydraulic Top Out (HTO) piston

Specification:

• Adjustable Damping : Yes
• Compressed Length : 18.5
• Extended Length : 26.47
• Finish : Clear-anodized
• Gas Charged : Yes
• Lower Mount Code : OEM
• Lower Mount Type : Eyelet
• Position : Rear
• Shaft Diameter : 5/8"
• Travel Length : 7.97
• Type : Coil-Over
• Upper Mount Code : Eyelet
• Upper Mount Type : OEM

FOX 2.5 Performance Series HTO shock is a bolt-on shock loaded with position-sensitive technology, vehicle-specific valving, and larger pistons to improve on and off-road performance. A type II anodized aluminum body efficiently dissipates heat and prevents corrosion. The 2.5-inch shock body features an internal floating piston (IFP) to separate the shock oil from the high-pressure nitrogen, optimizing damping. The 2.5-inch HTO shocks for the Ford Bronco reuse the existing OE spring.

Hydraulic Top Out (HTO) technology offers usable position-sensitive rebound damping control on and off the pavement. HTO reduces harsh top-outs and increases comfort by forcing shock oil through a secondary shim stack to slow the shock shaft speed; HTO is particularly beneficial after installing heavier, aggressive tires and in applications lifted higher than the OEM specification.

Bolt-on 2.5 Performance Series HTO shocks to increase damping capacity and ride in comfort with position-sensitive rebound control.

Brand: Fox

• 2021-2026 Ford Bronco
